Ramsey Winch - QM 5000 H, 12V, with 12 ft. pendant
+ Tap or click image to enlarge
Planetary Electric Winch with 5,000 lb Line Pull
$1,880.20
$2,212.00
SKU 111107
Manufacturer Lead Time: 3-10 Weeks
Product Details
- Use with a class-three rear receiver hitch with 5,000 lbs. minimum weight carrying (WC) rating
- Cam action clutch disengages planetary gear system for free spooling
- Proven 3-stage planetary gear system design for fast line speed
- Weather resistant fully integrated solenoid assembly
- Strong automatic load-holding brake
- 12 Ft. wire pendant remote
- Anti-theft locking pin
- Hawse fairlead
- Limited lifetime warranty
- Made in the USA
Specifications
| Rated Line Pull | 5,000 Lbs / 2,268 Kg |
| Note | Rated line pull is based on the first layer of cable. Rated line speed is based on cable with No Load. |
| Gear Ratio | 294:1 |
| Weight w/o Cable | 74 Lbs / 34 Kg |
| Brake | Yes |
| Cable | Includes Cable |
| Drum Size (L x F x B) | 5.50 x 5.50 x 2.50 In / 140 x 140 x 64 MM |
| Cable Capacity | 80 Ft / 24.4 M |
| Recommend Cable Size | 1/4 In / 6.4 MM, 5/16 In / 7.9 MM |
| 1st Layer Line Speed | 39 Ft/Min / 11.9 M/Min |
| Motor Output | 3.8 HP |
| Motor Type | Series Wound |
| Voltage | 12V, 24V |
| Fairlead | Hawse |
| Clutch Type | Cam Action |
| Clutch Control | Manual |
How To Use
Winches, capstans and hoists are not intended to be used for lifting or moving of persons.
The last 5 wraps of cable must be left on the drum to assist the cable clamp in holding the load.
