96" SPREADER UNDER TAILGATE LS DIS.

+ Tap or click image to enlarge

UNDER TAILGATE DIRECT MOUNT LS DISCHARGE

$4,605.00 $6,140.00

SKU 92425SSA

Product Details

PART #:

92425SSA

SPREADING MATERIAL:

Bulk Salt; 50/50 Salt/Sand mix

SPREADING WIDTH:

4-40 ft.

CAPACITY:

N/A

VEHICLE APPLICATION:

96" wide Dump Bodies

CHUTE:

N/A

WEIGHT:

460 lbs.

OVERALL HEIGHT:

18" (Depth)

OVERALL WIDTH:

38"/39.5"/41" (Spinner Adj. Height)

OVERALL LENGTH:

96"

HOPPER WIDTH:

N/A

HOPPER LENGTH:

N/A

TOP SCREEN:

N/A

COVER:

N/A

VIBRATOR:

N/A

INVERTED V:

N/A

FRAME:

Stainless Steel

HOPPER:

N/A

POWER SOURCE:

2 Independent Direct Drive Hydraulic Motors

FEED MECHANISM:

6" Auger w/ 3/8" flighting

SPINNER:

18"

CONTROLLER:

N/A

MOUNTING:

Dump Body Mounting Hardware Included

• Stainless steel
• Material spread up to 40'
• Hydraulic power drives auger and spinner
• Left discharge
• 10-gauge trough has 3-point hinged bottom cover for easy access to entire auger assembly and one-person cleanout.
• 6" auger with 3/8" flighting, includes auger screen
• 8" side shields
• 18" poly spinner
• Sealed, self-aligning 1-1/4" diameter bearing with grease fitting
• Low-speed, high-torque orbital motors.
• Hydraulic safety lockout system.
• Optional stainless steel spill shields (924F0106SSPR)
